LUZ-S150-DM 100–240VAC 1.5A Push Dimmer Controller – AC Triac RF Dimmer

The LUZ-S150-DM is a high-performance AC Triac RF dimmer designed for precise and smooth lighting control. Supporting a wide input range of 100–240VAC, it offers compatibility with a variety of lighting loads including incandescent lamps, HV halogen lamps, and dimmable LED fixtures. Featuring both RF 2.4GHz and Push Dim input signals, it provides flexible operation for modern lighting systems. With configurable leading-edge or trailing-edge dimming via DIP switch, and adjustable minimum brightness, this controller delivers tailored light performance. Built-in protections against overheating, overload, and automatic recovery ensure reliability and long-lasting performance in any lighting setup.

Key Features:

Universal input range (100–240VAC) for versatile installation

Supports multiple load types: incandescent, HV halogen, and dimmable LED lamps

Dual control: RF 2.4GHz remote and Push Dim input

Selectable leading or trailing-edge dimming via DIP switch

Adjustable minimum brightness for precise customization

Integrated overheat, overload, and auto-recovery protection

Key Specifications:

Input Voltage: 100–240VAC

Output Current: 1.5A × 1 Channel

Output Power: 150W / 360W (at 100V / 240V)

Input Signal: RF 2.4GHz + Push Dim

Load Type: Incandescent lamps, HV halogen lamps, dimmable LED lamps

Dimming Mode: Leading-edge or trailing-edge (selectable)

Protection: Overheat, overload, and auto-recovery

Frequency: RF 2.4GHz

Control Channels: 1CH

Housing: Compact, heat-resistant design

Certifications: CE, RoHS

Ideal Usage:

Gardens & Pathways: Enables smooth dimming for decorative or accent lighting circuits

Driveways & Entrances: Provides adjustable illumination for safety and energy saving

Patios & Terraces: Offers precise brightness control for ambient outdoor lighting

Hotels & Resorts: Ideal for guest room, corridor, and lobby lighting management

Retail & Commercial Spaces: Ensures optimal light tuning for displays and showroom setups
